CNG Metering Post

The Compac Metering Post is designed to provide safe and reliable metered filling: from a static supply tank to a mobile tanker or vice versa.

The Metering Post is controlled by a C4000 board and uses the Compac KG80 meter. It also works well as a simple, no frills dispenser in commercial applications.

All materials used in our CNG Metering Posts are made from high quality stainless steel to ensure corrosion resistance. The metering post is designed for ease of service.

Metering Post General Specifications

  • Tubing, sheetmetal, framing and brackets
  • Fixed pressure refuelling (adjustable)
  • LCD display with backlighting
  • Push to start button
  • Stop button to close solenoid and terminate fill
  • Pressure gauges Ø100 dual scale 0-400 bar
  • Manual outlet isolation valve
  • Hose options: ¾” and ½”
  • Coupler (to be specified)

Metering Post Performance

  • Flowrate up to 100 kg/min (Flow rate dependant on upstream and downstream conditions, hose selection and maximum inlet pressure)
  • Accuracy ± 1% on CNG gas for entire system
  • Maximum inlet pressure 275 bar and 350 bar models
  • Power 230V, 50 Hz ±10%
  • Ambient temperature range -25°C to +55°C (-40°C optional)
  • CNG temperature range -40°C to +75°C


Metering Post Options

  • Electro-mechanical totaliser 7 digits
  • Display units of measure: kg, m³ or litre equivalent
  • Gauges with psi and either bar, MPa or kg/cm²
  • Decals to suit customer requirements
  • PC and POS systems interfaces
  • Other options available on request
